high quality yoke plate/overhead transmission line hardware

high quality yoke plate/overhead transmission line hardware

high quality yoke plate/overhead transmission line hardware
high quality yoke plate/overhead transmission line hardwarehigh quality yoke plate/overhead transmission line hardwarehigh quality yoke plate/overhead transmission line hardwarehigh quality yoke plate/overhead transmission line hardwarehigh quality yoke plate/overhead transmission line hardware
CategoriesBracing & Bracket
AlbumView larger image
BrandTUOFA
Model590*40*6mm
MaterialQ235B
SurfaceHot Dip Galvanized
Galvanized ThicknessAccording to Customer's Requirement
FOB portTianjin
Terms of PaymentL/C, T/T
Update Time2019-01-19
Detail Information
High quality  yoke plate/overhead transmission line hardware used for electric power lines.

We have all kinds of sizes and also accept customized. Welcome to contact to me,we would provide our best service and best products to you!

DB Adjuster Plate

 yoke link plate,
 hot-dip
 galvanized steel

Catalog.No.Dimensions(mm)Rated
Failure Load(kn)
Weight(kg)
ØLL1L2L3L4b
DB-718709512014517016701.7
DB-102080110140170200161002.7
DB-1224100135170205240161203.2
DB-1626110125140155170181604.1
DB-2030120135150165180262007.4
DB-25331201401601802003025011.5
DB-30391201401601802003230012.5
DB-60511351601852102354260021.6
DB-5024451401651902152403850018.5
DB-5032451401852302753203850014.4
DB-21G26120135150165180203106.2
DB-32G33120140160180200383209.2
